Design Pressure: 19.2 bar
Maximun input pressure: 16 bar / 8 bar
Cut off-Precision class: RG5-SG10
Flanged Ends: ANSI150 – PN16
Output pressure: 8 – 4400 mbar
Certificates : EN 334, DIN 3381, EU 97/23/EC, EN 10204 3.1B, EN 45014
Construction material:
Body: Steel A216 WCB, Spheroid cast-iron
Cover: Stell
Membrane: Reinfrorced rubber |
| |
Technical Charactheristics |
|
 Download the PDF so as to se the technical caracteristics of the specific product. |
